| Network |
2G bands |
GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only) |
| 3G bands |
HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 - Global, USA |
| 4G bands |
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 32, 38, 39, 40, 41, 66 - Global |
| Speed |
HSPA 42.2/5.76 Mbps, LTE (6CA) Cat18 1200/200 Mbps |
| Launch |
Announced |
2018, February 25 |
| Status |
Available. Released 2018, March 09 |
| Body |
Dimensions |
147.7 x 68.7 x 8.5 mm (5.81 x 2.70 x 0.33 in) |
| Weight |
163 g (5.75 oz) |
| Build |
Glass front (Gorilla Glass 5), glass back (Gorilla Glass 5), aluminum frame |
| SIM |
Single SIM (Nano-SIM) or Hybrid Dual SIM (Nano-SIM, dual stand-by) |
| Display |
Type |
Super AMOLED, HDR10 |
| Size |
5.8 inches, 84.8 cm |
| Resolution |
1440 x 2960 pixels, 18.5:9 ratio (~570 ppi density) |
| Protection |
Corning Gorilla Glass 5 |
| Platform |
OS |
Android 8.0 (Oreo), upgradable to Android 10, One UI 2.5 |
| Chipset |
Exynos 9810 (10 nm) - EMEA |
| CPU |
Octa-core (4x2.7 GHz Mongoose M3 & 4x1.8 GHz Cortex-A55) - EMEA |
| GPU |
Mali-G72 MP18 - EMEA |
| Memory |
Card slot |
microSDXC (uses shared SIM slot) - dual SIM model only |
| Internal |
64GB 4GB RAM, 128GB 4GB RAM, 256GB 4GB RAM |
| Main Camera |
Single |
12 MP, f/1.5-2.4, 26mm (wide), 1/2.55", 1.4µm, dual pixel PDAF, OIS |
| Features |
LED flash, auto-HDR, panorama |
| Video |
4K@30/60fps, 1080p@30/60/240fps, 720p@960fps, HDR, stereo sound rec., gyro-EIS & OIS (30fps) |
| Selfie camera |
Dual |
8 MP, f/1.7, 25mm (wide), 1/3.6", 1.22µm, AF |
| Features |
HDR |
| Video |
1440p@30fps |
| Sound |
Loudspeaker |
Yes, with stereo speakers |
| 3.5mm jack |
Yes |
| Comms |
WLAN |
Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct |
| Bluetooth |
5.0, A2DP, LE, aptX |
| Positioning |
GPS, GLONASS, BDS, GALILEO |
| NFC |
Yes |
| Radio |
FM radio (USA & Canada only) |
| USB |
USB Type-C 3.1 |
| Features |
Sensors |
Iris scanner, fingerprint (rear-mounted), accelerometer, gyro, proximity, compass, barometer, heart rate, SpO2 |
| Battery |
Type |
Li-Ion 3000 mAh, non-removable (11.55 Wh) |
| Charging |
15W wired, QC2 |
| Misc |
Colors |
Midnight Black, Coral Blue, Titanium Gray, Lilac Purple, Burgundy Red, Sunrise Gold, Ice Blue |
| Models |
SM-G960F, SM-G960, SM-G960F, SM-G960U, SM-G960W, SM-G9600, SM-G960U1, SM-G960N, SCV38, SM-G960X, SC-02K |
| SAR |
0.63 W/kg (head) 0.96 W/kg (body) |
| SAR EU |
0.36 W/kg (head) 1.18 W/kg (body) |
