| Network |
2G bands |
GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (Dual SIM model only) |
| 3G bands |
HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 |
| 4G bands |
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 32, 38, 39, 40, 41, 66 - International |
| 5G bands |
1, 2, 3, 5, 7, 8, 12, 20, 25, 28, 38, 40, 41, 66, 75, 77, 78 SA/NSA/Sub6 - International |
| Speed |
HSPA 42.2/5.76 Mbps, LTE (7CA) Cat20 2000/200 Mbps, 5G (5+ Gbps DL) |
| Launch |
Announced |
2022, February 09 |
| Status |
Available. Released 2022, February 25 |
| Body |
Dimensions |
146 x 70.6 x 7.6 mm (5.75 x 2.78 x 0.30 in) |
| Weight |
167 g / 168 g (mmWave) (5.89 oz) |
| Build |
Glass front (Gorilla Glass Victus+), glass back (Gorilla Glass Victus+), aluminum frame |
| SIM |
Nano-SIM and eSIM or Dual SIM (2 Nano-SIMs and eSIM, dual stand-by) |
| Display |
Type |
Dynamic AMOLED 2X, 120Hz, HDR10+, 1300 nits (peak) |
| Size |
6.1 inches, 90.1 cm |
| Resolution |
1080 x 2340 pixels, 19.5:9 ratio (~425 ppi density) |
| Protection |
Corning Gorilla Glass Victus+ |
| Platform |
OS |
Android 12, up to 4 major Android upgrades, One UI 6.1.1 |
| Chipset |
Exynos 2200 (4 nm) - Europe |
| CPU |
Octa-core (1x2.8 GHz Cortex-X2 & 3x2.50 GHz Cortex-A710 & 4x1.8 GHz Cortex-A510) - Europe |
| GPU |
Xclipse 920 - Europe |
| Memory |
Card slot |
No |
| Internal |
128GB 8GB RAM, 256GB 8GB RAM |
| Main Camera |
Triple |
50 MP, f/1.8, 23mm (wide), 1/1.56", 1.0µm, dual pixel PDAF, OIS |
| Features |
LED flash, auto-HDR, panorama |
| Video |
8K@24fps, 4K@30/60fps, 1080p@30/60/240fps, 720p@960fps, HDR10+, stereo sound rec., gyro-EIS |
| Selfie camera |
Single |
10 MP, f/2.2, 26mm (wide), 1/3.24", 1.22µm, dual pixel PDAF |
| Features |
HDR |
| Video |
4K@30/60fps, 1080p@30fps |
| Sound |
Loudspeaker |
Yes, with stereo speakers |
| 3.5mm jack |
No |
| Comms |
WLAN |
Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, Wi-Fi Direct |
| Bluetooth |
5.2, A2DP, LE |
| Positioning |
GPS, GLONASS, BDS, GALILEO |
| NFC |
Yes |
| Radio |
No |
| USB |
USB Type-C 3.2, OTG |
| Features |
Sensors |
Fingerprint (under display, ultrasonic), accelerometer, gyro, proximity, compass, barometer |
| Battery |
Type |
Li-Ion 3700 mAh, non-removable |
| Charging |
25W wired, PD3.0 |
| Misc |
Colors |
Phantom Black, White, Pink Gold, Green, Graphite, Sky Blue, Violet, Cream, Bora Purple |
| Models |
SM-S901B, SM-S901B/DS, SM-S901U, SM-S901U1, SM-S901W, SM-S901N, SM-S9010, SM-S901E, SM-S901E/DS |
| SAR |
1.03 W/kg (head) 1.15 W/kg (body) |
| SAR EU |
1.21 W/kg (head) 1.59 W/kg (body) |
