| Network |
2G bands |
GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (Dual SIM model only) |
| 3G bands |
HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 |
| 4G bands |
1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 18, 19, 20, 25, 26, 28, 30, 38, 39, 40, 41, 46, 48, 66, 71 - SM-G996U1 |
| 5G bands |
2, 5, 25, 41, 66, 71, 260, 261 SA/NSA/Sub6/mmWave - SM-G996U1 |
| Speed |
HSPA 42.2/5.76 Mbps, LTE (7CA) Cat20 2000/200 Mbps, 5G (5+ Gbps DL) |
| Launch |
Announced |
2021, January 14 |
| Status |
Available. Released 2021, January 29 |
| Body |
Dimensions |
161.5 x 75.6 x 7.8 mm (6.36 x 2.98 x 0.31 in) |
| Weight |
200 g (Sub6), 202 g (mmWave) (7.05 oz) |
| Build |
Glass front (Gorilla Glass Victus), glass back (Gorilla Glass Victus), aluminum frame |
| SIM |
Nano-SIM and eSIM or Dual SIM (2 Nano-SIMs and eSIM, dual stand-by) |
| Display |
Type |
Dynamic AMOLED 2X, 120Hz, HDR10+, 1300 nits (peak) |
| Size |
6.7 inches, 107.8 cm |
| Resolution |
1080 x 2400 pixels, 20:9 ratio (~394 ppi density) |
| Protection |
Corning Gorilla Glass Victus |
| Platform |
OS |
Android 11, up to 4 major Android upgrades, One UI 6.1 |
| Chipset |
Exynos 2100 (5 nm) - International |
| CPU |
Octa-core (1x2.9 GHz Cortex-X1 & 3x2.80 GHz Cortex-A78 & 4x2.2 GHz Cortex-A55) - International |
| GPU |
Mali-G78 MP14 - International |
| Memory |
Card slot |
No |
| Internal |
128GB 8GB RAM, 256GB 8GB RAM |
| Main Camera |
Triple |
12 MP, f/1.8, 26mm (wide), 1/1.76", 1.8µm, dual pixel PDAF, OIS |
| Features |
LED flash, auto-HDR, panorama |
| Video |
8K@24fps, 4K@30/60fps, 1080p@30/60/240fps, 720p@960fps, HDR10+, stereo sound rec., gyro-EIS |
| Selfie camera |
Single |
10 MP, f/2.2, 26mm (wide), 1/3.24", 1.22µm, dual pixel PDAF |
| Features |
HDR |
| Video |
4K@30/60fps, 1080p@30fps |
| Sound |
Loudspeaker |
Yes, with stereo speakers |
| 3.5mm jack |
No |
| Comms |
WLAN |
Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, Wi-Fi Direct |
| Bluetooth |
5.0, A2DP, LE |
| Positioning |
GPS, GLONASS, BDS, GALILEO |
| NFC |
Yes |
| Radio |
FM radio (Snapdragon model only; market/operator dependent) |
| USB |
USB Type-C 3.2, OTG |
| Features |
Sensors |
Fingerprint (under display, ultrasonic), accelerometer, gyro, proximity, compass, barometer |
| Battery |
Type |
Li-Ion 4800 mAh, non-removable |
| Charging |
25W wired, PD3.0 |
| Misc |
Colors |
Phantom Black, Phantom Silver, Phantom Violet, Phantom Pink, Phantom Gold, Phantom Red |
| Models |
SM-G996B, SM-G996B/DS, SM-G996U, SM-G996U1, SM-G996W, SM-G996N, SM-G9960 |
| SAR |
0.65 W/kg (head) 0.95 W/kg (body) |
| SAR EU |
0.54 W/kg (head) 1.33 W/kg (body) |
