| Network |
2G bands |
GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only) |
| 3G bands |
HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 |
| 4G bands |
1, 2, 3, 4, 5, 7, 12, 14, 20, 29, 30, 38, 39, 40, 41, 46, 48, 66 - SM-A536U |
| 5G bands |
2, 5, 41, 66, 77, 78 SA/NSA/Sub6/mmWave - SM-A536U |
| Speed |
HSPA, LTE, 5G |
| Launch |
Announced |
2022, March 17 |
| Status |
Available. Released 2022, March 24 |
| Body |
Dimensions |
159.6 x 74.8 x 8.1 mm (6.28 x 2.94 x 0.32 in) |
| Weight |
189 g (6.67 oz) |
| Build |
Glass front (Gorilla Glass 5), plastic frame, plastic back |
| SIM |
Single SIM (Nano-SIM) or Hybrid Dual SIM (Nano-SIM, dual stand-by) |
| Display |
Type |
Super AMOLED, 120Hz, 800 nits (HBM) |
| Size |
6.5 inches, 102.0 cm |
| Resolution |
1080 x 2400 pixels, 20:9 ratio (~405 ppi density) |
| Protection |
Corning Gorilla Glass 5 |
| Platform |
OS |
Android 12, up to 4 major Android upgrades, One UI 6 |
| Chipset |
Exynos 1280 (5 nm) |
| CPU |
Octa-core (2x2.4 GHz Cortex-A78 & 6x2.0 GHz Cortex-A55) |
| GPU |
Mali-G68 |
| Memory |
Card slot |
microSDXC (uses shared SIM slot) |
| Internal |
128GB 4GB RAM, 128GB 6GB RAM, 128GB 8GB RAM, 256GB 6GB RAM, 256GB 8GB RAM |
| Main Camera |
Quad |
64 MP, f/1.8, 26mm (wide), 0.8µm, PDAF, OIS |
| Features |
LED flash, panorama, HDR |
| Video |
4K@30fps, 1080p@30/60fps; gyro-EIS |
| Selfie camera |
Single |
32 MP, f/2.2, 26mm (wide), 1/2.8", 0.8µm |
| Features |
HDR |
| Video |
4K@30fps, 1080p@30fps |
| Sound |
Loudspeaker |
Yes, with stereo speakers |
| 3.5mm jack |
No |
| Comms |
WLAN |
Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct |
| Bluetooth |
5.1, A2DP, LE |
| Positioning |
GPS, GLONASS, GALILEO, BDS |
| NFC |
Yes (market/region dependent) |
| Radio |
No |
| USB |
USB Type-C 2.0, OTG |
| Features |
Sensors |
Fingerprint (under display, optical), accelerometer, gyro, compass, barometer (market/region dependent) |
| Battery |
Type |
Li-Po 5000 mAh, non-removable |
| Charging |
25W wired |
| Misc |
Colors |
Black, White, Blue, Peach |
| Models |
SM-A536B, SM-A536B/DS, SM-A536U, SM-A536U1, SM-A5360, SM-A536E, SM-A536E/DS, SM-A536V, SM-A536W, SM-A536N, SM-S536DL |
| SAR |
0.75 W/kg (head) 1.58 W/kg (body) |
| SAR EU |
0.89 W/kg (head) 1.60 W/kg (body) |
