| Network |
2G bands |
GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only) |
| 3G bands |
HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 - Global, USA |
| 4G bands |
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 32, 38, 39, 40, 41, 66 - Global |
| Speed |
HSPA 42.2/5.76 Mbps, LTE (7CA) Cat20 2000/150 Mbps |
| Launch |
Announced |
2019, February 20 |
| Status |
Available. Released 2019, March 08 |
| Body |
Dimensions |
142.2 x 69.9 x 7.9 mm (5.60 x 2.75 x 0.31 in) |
| Weight |
150 g (5.29 oz) |
| Build |
Glass front (Gorilla Glass 5), glass back (Gorilla Glass 5), aluminum frame |
| SIM |
Single SIM (Nano-SIM) or Hybrid Dual SIM (Nano-SIM, dual stand-by) |
| Display |
Type |
Dynamic AMOLED, HDR10+ |
| Size |
5.8 inches, 82.8 cm |
| Resolution |
1080 x 2280 pixels, 19:9 ratio (~438 ppi density) |
| Protection |
Corning Gorilla Glass 5 |
| Platform |
OS |
Android 9.0 (Pie), upgradable to Android 12, One UI 4.1 |
| Chipset |
Exynos 9820 (8 nm) - EMEA/LATAM |
| CPU |
Octa-core (2x2.73 GHz Mongoose M4 & 2x2.31 GHz Cortex-A75 & 4x1.95 GHz Cortex-A55) - EMEA/LATAM |
| GPU |
Mali-G76 MP12 - EMEA/LATAM |
| Memory |
Card slot |
microSDXC (uses shared SIM slot) - dual SIM model only |
| Internal |
128GB 6GB RAM, 128GB 8GB RAM, 256GB 8GB RAM |
| Main Camera |
Dual |
12 MP, f/1.5-2.4, 26mm (wide), 1/2.55", 1.4µm, dual pixel PDAF, OIS |
| Features |
LED flash, auto-HDR, panorama |
| Video |
4K@60fps (no EIS), 4K@30fps, 1080p@30/60/240fps, 720p@960fps, HDR10+, stereo sound rec., gyro-EIS & OIS |
| Selfie camera |
Single |
10 MP, f/1.9, 26mm (wide), 1/3", 1.22µm, dual pixel PDAF |
| Features |
HDR |
| Video |
4K@30/60fps, 1080p@30fps |
| Sound |
Loudspeaker |
Yes, with stereo speakers |
| 3.5mm jack |
Yes |
| Comms |
WLAN |
Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, Wi-Fi Direct |
| Bluetooth |
5.0, A2DP, LE, aptX |
| Positioning |
GPS, GLONASS, BDS, GALILEO |
| NFC |
Yes |
| Radio |
FM radio (USA & Canada only) |
| USB |
USB Type-C 3.1 |
| Features |
Sensors |
Fingerprint (side-mounted), accelerometer, gyro, proximity, compass, barometer |
| Battery |
Type |
Li-Ion 3100 mAh, non-removable |
| Charging |
15W wired, PD2.0 |
| Misc |
Colors |
Prism White, Prism Black, Prism Green, Prism Blue, Canary Yellow, Flamingo Pink |
| Models |
SM-G970F, SM-G970U, SM-G970W, SM-G9700, SM-G970U1, SM-G970N, SM-G970X |
| SAR |
0.56 W/kg (head) 0.70 W/kg (body) |
| SAR EU |
0.58 W/kg (head) 1.57 W/kg (body) |
