| Network |
2G bands |
GSM 850 / 900 / 1800 / 1900 - A1522 (GSM), A1522 (CDMA), A1524 |
| 3G bands |
HSDPA 850 / 900 / 1700 / 1900 / 2100 - A1522 (GSM), A1522 (CDMA), A1524 |
| 4G bands |
1, 2, 3, 4, 5, 7, 8, 13, 17, 18, 19, 20, 25, 26, 28, 29 - A1522 GSM, A1522 CDMA |
| Speed |
HSPA 42.2/5.76 Mbps, LTE Cat4 150/50 Mbps, EV-DO Rev.A 3.1 Mbps |
| Launch |
Announced |
2014, September 09. Released 2014, September 19 |
| Status |
Discontinued |
| Body |
Dimensions |
158.1 x 77.8 x 7.1 mm (6.22 x 3.06 x 0.28 in) |
| Weight |
172 g (6.07 oz) |
| Build |
Glass front (Corning-made glass), aluminum back, aluminum frame |
| SIM |
Nano-SIM |
| Display |
Type |
IPS LCD |
| Size |
5.5 inches, 83.4 cm |
| Resolution |
1080 x 1920 pixels, 16:9 ratio (~401 ppi density) |
| Protection |
Ion-strengthened glass, oleophobic coating |
| Platform |
OS |
iOS 8, upgradable to iOS 12.5.6 |
| Chipset |
Apple A8 (20 nm) |
| CPU |
Dual-core 1.4 GHz Typhoon (ARM v8-based) |
| GPU |
PowerVR GX6450 (quad-core graphics) |
| Memory |
Card slot |
No |
| Internal |
16GB 1GB RAM, 64GB 1GB RAM, 128GB 1GB RAM |
| Main Camera |
Single |
8 MP, f/2.2, 29mm (standard), 1/3.0", 1.5µm, PDAF, OIS |
| Features |
Dual-LED dual-tone flash, HDR |
| Video |
1080p@60fps, 720p@240fps |
| Selfie camera |
Single |
1.2 MP, f/2.2, 31mm (standard) |
| Features |
face detection, HDR, FaceTime over Wi-Fi or Cellular |
| Video |
720p@30fps |
| Sound |
Loudspeaker |
Yes |
| 3.5mm jack |
Yes |
| Comms |
WLAN |
Wi-Fi 802.11 a/b/g/n/ac, dual-band, hotspot |
| Bluetooth |
4.0, A2DP, LE |
| Positioning |
GPS, GLONASS |
| NFC |
Yes (Apple Pay only) |
| Radio |
No |
| USB |
Lightning, USB 2.0 |
| Features |
Sensors |
Fingerprint (front-mounted), accelerometer, gyro, proximity, compass, barometer |
| Battery |
Type |
Li-Po 2915 mAh, non-removable (11.1 Wh) |
| Stand-by |
Up to 384 h (3G) |
| Talk time |
Up to 24 h (3G) |
| Misc |
Colors |
Space Gray, Silver, Gold |
| Models |
A1522, A1524, iPhone7,1 |
| SAR |
1.19 W/kg (head) 1.19 W/kg (body) |
| SAR EU |
0.99 W/kg (head) 0.91 W/kg (body) |
| Price |
About 420 EUR |
